Hailo M80

Adjustable aluminium Multipurpose ladder. Slides together, with safety joints and locking handles for height adjustment.

Detail Detail
Select number of rungs
4 x 6

7524-157  |  4 x 6 Rungs



  • The key features

    • For use as a lean-to ladder, extension ladder and a double-sided step ladder and stair ladder
    • Height adjustable using position lock handles on sides at various levels
    • 2 safety joints (can be locked and released) for adjustment when used as a step ladder and lean-to ladder

    Other product advantages

    • Safe, versatile and adjustable
    • Automatic position lock system
    • Rung by rung height adjustment
    • Inner section of ladder: longitudinal profile rungs (27 x 27 mm)
    • Telescopic section: longitudinal profile rungs (30 x 30 mm)
    • Maximum load capacity 150 kg

    Properties

    • Rungs: 4x6
    • Working height:
      as trestle ladder max. 420 cm,

      as lean-to ladder max. 675 cm
    • Weight: approx. 18.1 kg
  • Specifications

    Telescopic function
    Can be used as lean-to ladder or free-standing ladder
    Can be used in a free-standing position
    Can be used as lean-to ladder
    Step adjustment
    Number of steps 4 x 6
    Width/depth required for setting up trestle ladder A = 64 cm, B = 180 cm
    Height of trestle ladder 285 cm
    Height of lean-to ladder 566 cm
    Max. working height 675 cm
    Max. working height of trestle ladder 420 cm
    Max. working height of lean-to ladder 675 cm
    Dimensions of packaging (HxWxD) A = 167 cm, B = 64 cm, C = 25 cm
    Step adjustment max. 125 cm
    Weight 18,1 kg

    Specifications


    Telescopic function

    Can be used as lean-to ladder or free-standing ladder

    Can be used in a free-standing position

    Can be used as lean-to ladder

    Step adjustment

    Number of steps
    4 x 6

    Width/depth required for setting up trestle ladder
    A = 64 cm, B = 180 cm

    Height of trestle ladder
    285 cm

    Height of lean-to ladder
    566 cm

    Max. working height
    675 cm

    Max. working height of trestle ladder
    420 cm

    Max. working height of lean-to ladder
    675 cm

    Dimensions of packaging (HxWxD)
    A = 167 cm, B = 64 cm, C = 25 cm

    Step adjustment max.
    125 cm

    Weight
    18,1 kg
  • Downloads

    Gebrauchsanleitung / Instructions for use Instructions_for_use_M80.pdf Download

    Downloads

    Gebrauchsanleitung / Instructions for use
    Instructions_for_use_M80.pdf
